Premium High-Efficiency Pool Heating

Orilux OX26 Pool Heat Pumps

Premium inverter pool heating for Geelong, the Bellarine Peninsula and Surf Coast. Explore seven OX26 models from 11.5kW to 40kW, designed for residential pools from approximately 25m³ through to 120m³.

Get an OX26 Quote

The Orilux OX26 Range

The Orilux OX26 is Orilux's premium high-efficiency pool heat pump range, offering capacities from 11.5kW through to 40kW.

The OX26 combines a Twin Rotary DC Compressor, Lightning Heat Exchanger and durable aluminium-alloy casing with intelligent Turbo and Smart heating modes.

With an operating air-temperature range from -20°C to 43°C, the OX26 provides a broad range of heating options for Geelong pool owners seeking to extend their swimming season.

11.5–40kW Turbo Heating Capacity
COP up to 26 A26 / W26 / RH80%
25–120m³ Advised Pool Volume
-20°C to 43°C Operating Air Temperature

Premium OX26 Technology

The OX26 range is engineered around variable-capacity heating, allowing the system to operate at different output levels depending on pool heating demand.

Turbo mode provides higher available heating output, while Smart mode offers modulated operation for temperature maintenance.

  • Twin Rotary DC Compressor
  • Lightning Heat Exchanger
  • Turbo heating mode
  • Smart heating mode
  • Optional cooling capability
  • Aluminium-alloy casing
  • 50mm water connections
  • -20°C to 43°C operating air temperature

Orilux OX26 Models

Select from seven heating capacities depending on pool size, required heating performance and operating conditions.

OX26 Series

OX26 11.5kW

Pool: 25–40m³

Turbo: 11.5kW

Smart: 8.6kW

Maximum COP: 23.0

OX26 Series

OX26 16.5kW

Pool: 35–60m³

Turbo: 16.5kW

Smart: 13.6kW

Maximum COP: 21.6

OX26 Series

OX26 19kW

Pool: 40–65m³

Turbo: 19.0kW

Smart: 15.0kW

Maximum COP: 22.1

OX26 Series

OX26 22kW

Pool: 45–75m³

Turbo: 22.0kW

Smart: 17.2kW

Maximum COP: 26.0

OX26 Series

OX26 26kW

Pool: 55–90m³

Turbo: 26.0kW

Smart: 21.7kW

Maximum COP: 20.3

OX26 Series

OX26 32kW

Pool: 65–105m³

Turbo: 32.0kW

Smart: 26.6kW

Maximum COP: 21.3

OX26 Series

OX26 40kW

Pool: 75–120m³

Turbo: 40.0kW

Smart: 33.5kW

Maximum COP: 20.7

OX26 Technical Specifications

Compare heating performance, COP, cooling capacity, sound, electrical requirements, water flow and physical dimensions across the complete Orilux OX26 range.

Specification OX26-11.5 OX26-16.5 OX26-19 OX26-22 OX26-26 OX26-32 OX26-40
Advised Pool Volume 25–40m³ 35–60m³ 40–65m³ 45–75m³ 55–90m³ 65–105m³ 75–120m³
Operating Air Temperature -20°C to 43°C
PERFORMANCE: AIR 26°C / WATER 26°C / HUMIDITY 80%
Turbo Heating Capacity 11.5kW 16.5kW 19.0kW 22.0kW 26.0kW 32.0kW 40.0kW
Smart Heating Capacity 8.6kW 13.6kW 15.0kW 17.2kW 21.7kW 26.6kW 33.5kW
COP Range 23.0–7.5 21.6–7.2 22.1–7.1 26.0–7.3 20.3–7.2 21.3–7.1 20.7–7.1
COP at 50% Capacity 14.4 14.5 14.3 15.5 14.6 14.5 14.4
PERFORMANCE: AIR 15°C / WATER 26°C / HUMIDITY 70%
Turbo Heating Capacity 8.1kW 11.0kW 13.0kW 15.4kW 17.5kW 21.7kW 27.6kW
Smart Heating Capacity 6.1kW 9.0kW 10.2kW 12.1kW 14.5kW 18.0kW 23.0kW
COP Range 8.5–5.4 8.6–5.1 8.0–4.9 8.9–5.2 7.7–5.3 8.1–5.2 7.9–4.8
COP at 50% Capacity 7.3 7.4 7.1 7.6 7.1 7.3 7.3
COOLING: AIR 35°C / WATER 28°C / HUMIDITY 80%
Cooling Capacity (Optional) 5.3kW 8.4kW 9.6kW 11.1kW 12.3kW 14.4kW 18.4kW
SOUND PERFORMANCE
Sound Pressure at 1m 38.1–45.4 dB(A) 41.3–47.2 41.9–47.9 42.2–49.9 41.1–50.3 42.5–50.9 41.8–51.9
Sound at 50% Capacity / 1m 39.1 dB(A) 43.0 42.8 43.6 44.4 45.5 45.8
Sound Pressure at 10m 18.1–25.4 dB(A) 21.3–27.2 21.9–27.9 22.2–29.9 21.1–30.3 22.5–30.9 21.8–31.9
COMPONENTS
Compressor Twin Rotary DC Compressor
Heat Exchanger Lightning Heat Exchanger
Casing Aluminium Alloy Casing
ELECTRICAL & HYDRAULIC
Power Supply 230V / 1Ph / 50Hz 230V / 1Ph / 50Hz 230V / 1Ph / 50Hz 230V / 1Ph / 50Hz 230V / 1Ph / 50Hz 230V / 1Ph / 50Hz 400V 3N~ / 50Hz
Water Connection 50mm
Rated Input Power at 15°C 0.14–1.50kW 0.21–2.16kW 0.26–2.65kW 0.27–2.96kW 0.38–3.30kW 0.44–4.17kW 0.58–5.75kW
Rated Input Current at 15°C 0.61–6.52A 0.91–9.39A 1.13–11.52A 1.17–12.87A 1.65–14.35A 1.91–18.13A 0.84–8.30A
Advised Water Flow 2–4m³/h 4–6m³/h 4–6m³/h 6.5–8.5m³/h 8–10m³/h 10–12m³/h 12–18m³/h
Maximum Input Current 10.0A 12.5A 16.0A 17.0A 22.5A 25.8A 11.5A
Circuit Breaker 12A 15A 19A 20A 27A 30A 14A
DIMENSIONS & WEIGHT
Dimensions L × W × H 923 × 427 × 661mm 1110 × 427 × 760mm 1160 × 427 × 760mm 1146 × 536 × 955mm 1146 × 536 × 955mm 1315 × 536 × 1055mm 1400 × 536 × 1250mm
Estimated Net Weight 67kg 83kg 86kg 110kg 113kg 133kg 180kg

Published performance figures are based on the stated test conditions. Actual heating capacity and COP vary according to ambient temperature, water temperature, humidity, operating capacity and installation conditions. Specifications are subject to modification without notice.

Performance in Cooler Geelong Conditions

For Victorian pools, performance at cooler ambient temperatures is particularly important.

The OX26 specification data includes heating performance at 15°C ambient air and 26°C pool water, allowing pool owners to better understand expected output outside ideal summer conditions.

  • OX26-11.5: 8.1kW Turbo at 15°C
  • OX26-16.5: 11.0kW Turbo at 15°C
  • OX26-19: 13.0kW Turbo at 15°C
  • OX26-22: 15.4kW Turbo at 15°C
  • OX26-26: 17.5kW Turbo at 15°C
  • OX26-32: 21.7kW Turbo at 15°C
  • OX26-40: 27.6kW Turbo at 15°C

Orilux OX26 Pool Heating Geelong

Geelong Pool Heating can help select an OX26 heat pump based on your pool size, location, desired water temperature and intended swimming season.

Correct sizing is particularly important around Geelong, the Bellarine Peninsula and Surf Coast, where cooler nights, changing spring temperatures and coastal exposure can increase pool heat loss.

Pool volume is a useful starting point, but surface area, target temperature, pool-cover use, wind exposure and desired heat-up time should also be considered.

Which OX26 Do You Need?

Tell us your pool dimensions, suburb, target water temperature and swimming season and we'll help determine the appropriate Orilux OX26 model for your pool.

Get My OX26 Recommendation
Pool Heat Pump Calculator

Find the Right Orilux Heat Pump

Enter your pool size and operating conditions to find a recommended Orilux pool heat pump. Sizing is adjusted for Geelong, Melbourne and cooler Victorian conditions to help avoid undersizing.

Most residential pools are around 1.3m–1.6m average depth.
This calculator is a sizing guide only. Final heat pump sizing should consider wind exposure, plumbing, pool cover use, target temperature, installation location and customer expectations.

Your Recommended Heat Pump Size

Based on your pool volume and selected operating conditions.

22kW
48,000L pool Cool climate sizing Performance sized
Orilux heat pumps use R290 refrigerant. COP ratings shown are maximum laboratory performance figures and may vary depending on air temperature, water temperature, humidity, installation conditions and operating mode.
